O-Ring Rubber Materials

O-RING and QUAD RING RUBBER MATERIALS

We have a wide range of rubber materials available for various applications. In addition to a number of standard compounds like : NBR, FPM, Perfluor, EPDM, MVQ and FMVQ, in various colours and hardness we also offer special materials: Encapsulated FPM/MVQ materials, ETP, TFE, HNBR and many others. In total we have over 40 different rubber materials available, however on customer request we can advise and develop special new "custom tailored" rubber materials.

NBR 70 NBR 90 FPM 75 Black
FPM 90 Black EPDM 70 MVQ 70
FMVQ 70 HNBR 70 Perfluor


Please select above your material of interest, and download the material specification (PDF).

Special EPDM Multiapproval drinking water compound NSF61 KTW ACS WRC FDA W270 EN681 W534 WRAS
Europe Seals has specially developed a "state of the art" EPDM rubber material. For the FOOD,WATER and HEATING Industry, meeting all international requirements; NSF61, WRC, KTW and FDA. This material has excellent performance in cold and hot water applications, f.i: water taps, industrial and consumer heating boilers, valves…etc.

EPDM Multi Approval

Click above for copy material specification or copy certificate.

For the French Market we do have a "French Water" ACS Approval EPDM Peroxide Cured material available.

Note: Europe Seals BV has a signed "Quality Monotoring Contract" with MPA- NRW in Dortmund Germany.

NBR 70 Multiapproval voor Water LPG and CNG
Water Approvals:

  • NSF61 KTW and WRC
LPG/CNG Approvals:
  • UL 157 Class F, G and J
  • Gastec R110 R67-01 and ISO 15500 Automotive

N7101 NBR70 (PDF)

Note; especially in Automotive LPG CNG applications an excellent gas and water resitancy is needed. (Cooling Systems)

EN 549 LPG and Natural Gas approved Rubber Materials
We have several EN549 KIWA  approved (also low Temperature - 20 C Class B2) rubber materials for for O Rings  and Rubber molded parts available.
NBR 60 Sh            EN 549   Class B2
NBR 70 Sh            EN 549  Class  B1
NBR 80-85 Sh     EN 549  Class  B2
HNBR 70 Sh        EN 549  Class  A1
Download KIWA Declaration

Coloured 0 Rings
We can offer various materials in different colours; Example NBR Red or Blue. Basic material and properties stay the same, excellent way for determination of different materials and sizes in order to prevent mixing failurers.

Some  coloured material examples are:


NBR 70 Red EP 80 Purple FPM 75 Green
FPM 75 Brown FPM 90 Brown HNBR 80 Blue

Note: more colours (RAL) in various materials possible.

ETP Viton® Extreme™ (O rings and X Rings)
Du Pont Dow elastomers has introduced high performance speciality materials that designed to meet the demanding requirements currently not met by traditional elastomers.This material combine the excellent thermal resistance of FPM with the unique resistance to chemicals, f.i: caustic applications, solvents, hydrocarbon oils, steam and acids.

ETP Viton Extreme (PDF)

FEP PFA Encapsulated O-Rings
FEP/TFA encapsulated O-Rings consists of a seamless FEP PFA jacket over an elastomer. This can be FPM or Silicone depending of the application requirements. This combination of a chemically resistant jacket over a low compression set elastomer provides unique properties for a range of high demanding applications in various Markets: chemical process industry, pharmaceutical, food and beverage, semiconductor industry…etc.
Note: Encapsulated seals are possible in many other shapes: Circular, Rectangular, Oval and Cam-seal shapes. (FDA AND USP Class VI)

Perfluor O-Rings and Molded parts.
Europe Seals can offer various Perfluor materials equal to Du Pont Dow ( Kalrez ® ), Parker ( Parofluor ® ), Greene Tweed ( Chemraz ® ) and others against very attractive pricing.
We not only offer industrial grades Perfluor (250 C°),  but also High Temperature grades (316 C°) in black, white and translucent (individually packed silicone free).
For Semiconductor Industry individually packed and "clean room" manufactured.



PERFLUOR BLACK PERFLUOR WHITE PERFLUOR CLEAR

O-Rings and Molded rubber parts for Automotive
Europe Seals supplies the full range materials used for Automotive Industry. Many Automotive OEM Material approvals are available. (including IMDS listings)
  • QS9000
  • TS16949
  • VDA Process Audit
PTFE O-Rings/Backup Rings/Spring Energized Seals
PTFE (polytetrafluoroethylene)is one of the most inert and chemically resistant materials that an O-Ring or seal can be made from. Moreover it has very low friction coefficient. There are some elastomers today that approach PTFE’s chemical and heat resistance like Perfluor Elastomers but they can be expensive and not always the best possible sealing sollution. PTFE can be modified with fillers to improve its properties depending on the applications requirements.

PTFE O-Rings are typically used in static applications while PTFE Spring Energized seals and piston rings will be used in dynamic applications where pressure and heat or high speed cycles are not possible with other materials.

PTFE Back-up Rings increases the sealing capabilities of an O-Ring to much higher pressure levels.

Hot Vulcanised (Spliced) O Rings

Vulcanization is a process which uses heat, rubber adhesive, pressure and time to chemically bond the two Cord ends together.
the Chemical and Temperature recistancy are the same as the Rubber Cord material specification.
(Major difference compared to O Ring Cord glued together!!   The Glue is limiting the Temperature and Chemical resistancy)

Benefits;

No Upper Diameter Limits
Quick Supply indoor Manufacturing
No Flash Lines
No expensive Mold Costs

 Rubber Materials;
-NBR 70 Sh
-EPDM 70 Sh
-FPM 70 Sh
